TSOP62.., TSOP64..
www.vishay.com
Vishay Semiconductors
VISHAY SEMICONDUCTOR GmbH STANDARD BAR CODE PRODUCT LABEL (Finished goods)
PLAIN WRITING
Item-description
Item-number
Selection-code
LOT-/serial-number
Data-code
Plant-code
Quantity
Accepted by
Packed by
Mixed code indicator
Origin
LONG BAR CODE TOP
Item-number
Plant-code
Sequence-number
Quantity
Total length
SHORT BAR CODE BOTTOM
Selection-code
Data-code
Batch-number
Filter
Total length
ABBREVIATION
-
INO
SEL
BATCH
COD
PTC
QTY
ACC
PCK
MIXED CODE
xxxxxxx+
TYPE
N
N
X
N
-
TYPE
X
N
X
-
-
LENGTH
18
8
3
10
3 (YWW)
2
8
-
-
-
Company logo
LENGTH
8
2
3
8
21
LENGTH
3
3
10
1
17
DRY PACKING
The reel is packed in an anti-humidity bag to protect the
devices from absorbing moisture during transportation and
storage.
Aluminum bag
Label
After more than 72 h under these conditions moisture
content will be too high for reflow soldering.
In case of moisture absorption, the devices will recover to
the former condition by drying under the following condition:
192 h at 40 °C + 5 °C / - 0 °C and < 5 % RH (dry air/nitrogen)
or
96 h at 60 °C + 5 °C and < 5 % RH for all device containers
or
24 h at 125 °C + 5 °C not suitable for reel or tubes.
An EIA JEDEC ? standard J-STD-020 level 4 label is included
on all dry bags.
Reel
15973
CAUTION
This bag contains
MOISTURE-SENSITIVE DEVICES
LEVEL
4
FINAL PACKING
The sealed reel is packed into a cardboard box. A secondary
cardboard box is used for shipping purposes.
RECOMMENDED METHOD OF STORAGE
Dry box storage is recommended as soon as the aluminum
bag has been opened to prevent moisture absorption. The
following conditions should be observed, if dry boxes are
not available:
? Storage temperature 10 °C to 30 °C
? Storage humidity ≤ 60 % RH max.
1. Shelf life in sealed bag: 12 months at < 40 °C and < 90 % relative
humidity (RH)
2. After this bag is opened, devices that will be subjected to soldering
reflow or equivalent processing (peak package body temp. 260 °C)
must be
2a. Mounted within 72 hours at factory condition of < 30 °C/60 % RH or
2b. Stored at < 5 % RH
3. Devices require baking befor mounting if:
Humidity Indicator Card is > 10 % when read at 23 °C ± 5 °C or
2a. or 2b. are not met.
4. If baking is required, devices may be baked for:
192 hours at 40 °C + 5 °C/- 0 °C and < 5 % RH (dry air/nitrogen) or
96 hours at 60 °C ± 5 °C and < 5 % RH for all device containers or
24 hours at 125 °C ± 5 °C not suitable for reels or tubes
Bag Seal Date:
(If blank, see barcode label)
Note: Level and body temperature defined by EIA JEDEC Standard J-STD-020
22522
EIA JEDEC standard J-STD-020 level 4 label is included
on all dry bags
Rev. 1.1, 05-Feb-14
10
Document Number: 82463
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
